Synchronous lifting system SM-Lift 400
Synchronous lifting system SM-Lift 400
SM-Lift 400 is designed for the synchronous lifting and shifting of large industrial equipment during installation, dismantling and relocation of production lines. The system controls the position of each support point to within 1 mm.
Features
- Synchronisation of up to 8 jacks from a single console
- Automatic levelling based on stroke sensors
- Overload and pressure-loss protection
- Operating temperature range −20…+50 °C
Scope of supply
Hydraulic power pack, 8 jacks rated at 50 t, set of high-pressure hoses, control console, transport cases.
SKU: SML-400-EN
Specifications
- Maximum capacity 400 t
- Number of jacks 8 × 50 t
- Stroke 300 mm
- Synchronisation accuracy ±1 mm
- Working pressure 700 bar
Related products
Gantry lift SM-Gantry 500
Hydraulic gantry lift with a 500-tonne capacity for installing equipment without a crane.
Hydraulic power pack SM-Power 700
Electro-hydraulic power pack, 700 bar, with a manifold for 4 independent lines.
Hydraulic jack SM-Jack 100
Low-profile hydraulic jack with a 100-tonne capacity for use in confined spaces.
